OI-351-24EG

1. With the ˝FRONT˝ mark facing

you, slide the anti-mold filter

up into the unit and then

lower the handle into the

groove on the unit.

2. After installing the anti-mold

filter, press the locations

marked by the arrows ( )

and close the air intake grille.

Care and Cleaning (continued)

Anti-mold filter The anti-mold filter behind the air intake grille should be checked and cleaned

at least once every two weeks.

How to remove the

anti-mold filter

1. Grasp both ends of the

air intake grille and

pull it out and up.

2. Push the anti-mold

filter up slightly, and

then pull it down.

Cleaning Use a vacuum cleaner to remove light dust. If there is sticky dust on the filter,

wash the filter in lukewarm, soapy water, rinse it in clean water and dry it.

How to replace the

anti-mold filter

Air intake grille

Anti-mold filter

Air intake grille

Anti-mold

filter

Insert into the groove on the unit.
